Progressive Stamping Die

Get a Price/Quote

Progressive Stamping Die Specification

Life Span
Up to 1 million strokes

Die Head
Multi-cavity

Working Process
Progressive stamping

Shaping Mode
Press dies

Material
High Speed Steel (HSS), Carbide

Application
Sheet metal part production, automotive, electronic components

Hardness
56-62 HRC

Tolerance
0.01 mm

Coating
Titanium Nitride (TiN), optional

Production Capacity
High-volume

Customization
Available as per drawing

Design Software Used
AutoCAD, SolidWorks

Die Base Material
Tool Steel

Surface Finish
Polished

Standard/Non-standard
Customizable

Max Sheet Thickness
Up to 3 mm

Corrosion Resistance
Yes

Punching Speed
Up to 80 strokes/min

About Progressive Stamping Die

Progressive Stamping Die supplied by us is used for metalworking methods that can encompass punching, bending, coining, etc thereby, modifying the metal shape. The feeding system pushes metal strip through all of the stations of a progressive stamping die and at each station one or more operations are performed until a finished part is made. Our company is the best place from where the customer can make the purchase of quality-assured Progressive Stamping Die at reasonable rates and on the promised time frame.

Precision Engineering for Demanding Applications

Built with high-quality tool steel and available with TiN coating, our progressive stamping dies excel in delivering consistent accuracy and longevity. They support a broad range of sheet metal thicknesses and complex shapes, serving automotive and electronics manufacturing sectors efficiently. The multi-cavity design increases productivity, while strict adherence to client specifications ensures optimal fit and function.

Advanced Surface Finish and Corrosion Resistance

Each die features a precision-polished finish, with an optional Titanium Nitride (TiN) coating for further surface hardness and corrosion protection. This advanced surface treatment prolongs die life and maintains superior part quality, even under intensive, high-speed stamping operations.

FAQs of Progressive Stamping Die:

Q: How is the progressive stamping die customized to client requirements?

A: Customization is achieved by working directly from your technical drawings using advanced design software like AutoCAD and SolidWorks. This ensures the final die precisely matches your part specification, dimensional tolerances, and production needs.

Q: What materials and surface finishes are used in the die construction?

A: The dies are manufactured from high-speed steel (HSS), carbide, and robust tool steel. A polished surface finish is standard, while an optional Titanium Nitride (TiN) coating is available to increase hardness, reduce wear, and improve corrosion resistance.

Q: When is Titanium Nitride (TiN) coating recommended for these dies?

A: TiN coating is ideal when working with high-volume runs, abrasive materials, or applications requiring extended die life and enhanced surface protection. Its especially recommended for applications demanding tighter tolerances and reduced maintenance intervals.

Q: Where can these progressive stamping dies be utilized?

A: These dies are widely used in sheet metal part manufacturing for automotive, electronics, and various industrial applications. They are suitable for any facility needing high-volume, precise, and durable stamping solutions.

Q: What is the process and speed of operation for this die?

A: The dies operate through a progressive stamping process, forming and punching up to 3 mm thick sheets at speeds reaching 80 strokes per minute. Multi-cavity heads enable the production of several parts simultaneously, optimizing throughput.

Q: How does the dies longevity benefit my production line?

A: With a lifespan of up to 1 million strokes and high corrosion resistance, these dies ensure fewer replacements and reduced downtime, providing consistent, repeatable results throughout extended production runs.
