ELECTRIC MOTOR STAMPING DIE

Get a Price/Quote

ELECTRIC MOTOR STAMPING DIE Specification

Core Material
Tool Steel / HSS

Tolerance
0.005 mm

Life Span
Up to 500,000 shots

Mould Base
High-grade alloy steel

Working Process
Precision pressing, CNC machining, Wire EDM

Material
Alloy Steel, Hardened

Shaping Mode
Press Mould

Punch Dies
Multi-cavity, Carbide Inserted

Die Head
Hardened Steel, Precision Fabricated

Hardness
HRC 58-62

Customization
Supported as per drawings or samples

Die Size
Customized as per client requirements

Finish
Polished / Anti-rust coated

Cavity Number
Single or Multi-cavity

Application
Electric motor rotor & stator lamination manufacturing

Automation
Compatible with automatic press lines

Surface Treatment
Heat treated & surface ground

Process Type
Progressive Die, Compound Die options available

About ELECTRIC MOTOR STAMPING DIE

Experience the ultimate in precision engineering with our Electric Motor Stamping Diedesigned for valorous manufacturing outcomes. Built with scarcity in mind, these fresh dies are carefully crafted and polished for rotor and stator lamination. With a robust HRC 58-62 hardness, invincible tool steel cores, and high-grade alloy mould base, our dies ensure reliability and long lifeup to 500,000 shots. Multiple cavity options, 0.005 mm tolerance, and full customization redefine productivity. Shop now and elevate your manufacturing capability with Indias leading exporter, supplier, and manufacturer.

Key Features & Applications of Electric Motor Stamping Die

Our Electric Motor Stamping Die boasts multi-cavity, carbide-inserted precision for invincible performance. Featuring CNC machining, sensitive 0.005 mm tolerance, heat-treated finishes, and options for progressive or compound die processes, these dies guarantee excellence. Suitable media include steel and HSS for motor laminations. Valorous in durability, these tools serve automatic press lines, ensuring efficient, repeatable, and high-value outputs. Customization transforms every die into the ultimate solution for electric motor manufacturing.

Sample Policy & Domestic Market Availability

Stock ready samples of our Electric Motor Stamping Die are available for evaluation, with quick dispatch across Indias main domestic market. Real-world testing allows you to assess market value before bulk orders. Our supply network ensures you receive fresh, high-quality dies with every shipment, supporting your production and development needs. The scarcity of precise tooling highlights the opportunitysecure your samples and be the first to benefit from our advanced manufacturing expertise.

FAQs of ELECTRIC MOTOR STAMPING DIE:

Q: How can I customize an Electric Motor Stamping Die to fit my specific requirements?

A: You can provide detailed drawings or physical samples to outline your specific needs. Our design team will collaborate with you to create the ultimate die tailored to your rotor or stator lamination application.

Q: What is the lifespan of the Electric Motor Stamping Die under continuous operation?

A: Built with hardened alloy steel and tool steel components, our stamping dies deliver up to 500,000 shots, combining durability with minimal maintenance for long-lasting service.

Q: What processes are used in manufacturing the stamping die to achieve high precision?

A: We use advanced CNC machining, wire EDM, and precision pressing to achieve strict tolerance levels of 0.005 mm and ensure optimal die performance.

Q: When can I expect my ordered stamping die or sample to be dispatched?

A: Stock ready samples are typically dispatched quickly upon order confirmation. Custom dies are manufactured as per client requirements and shipping timelines are communicated during the order process.

Q: Where are the Electric Motor Stamping Dies commonly applied?

A: These dies are primarily used in the progressive manufacturing of electric motor rotor and stator laminations, supporting automation in electric motor industries across India and beyond.
